Connectivity is limited including only 1 HDMI connection.

Slight gray in areas supposed to be black.

LCD

Type 32" (31.5" viewable) color TFT active matrix, wide LCD

Display Area 27.5" horizontal x 15.44" vertical; 32" diagonal

Native Resolution 1366x768

Contrast Ratio 3000:1 static (typ), 10,000:1 dynamic

Viewing Angles 176° horizontal, 176° vertical

Response Time 8ms

Light Source Long life, 50,000 hrs. (typ)

Brightness 450 cd/m2 (typ)

Aspect Ratio 16:9

Glass Surface Anti-glare, anti-reflective coat

INPUT

PC RGB analog (75 ohms, 0.7 Vp-p)

TV TV/cable, composite (RCA), component YPbPr/YCbCr, S-video

Audio 3.5mm mini stereo audio in/out and RCA (left/right) audio in

RGB Frequency Fh: 30~64kHz, Fv: 60~75Hz

Sync H/V separated (TTL)

Digital HDMI with HDCP and audio support (x2)

Tuner ATSC/NTSC/QAM

AUDIO OUTPUT

Speakers 2x10-watt Dolby® Digital sound

RCA Left/right

Digital Output SPDIF

COMPATIBILITY

PC 1360x768 (preferred), 1024x768, 1280x768

Mac®* Power Mac™ G3/G4/G5 up to 1280x1024

INPUT SIGNAL

TV/Video Comp. 480i, 480p, 720p, 1080i

CONNECTOR

Analog 15-pin mini D-sub (VGA)

Digital HDMI (x2)

Power 3-pin plug

RS-232 Control port

POWER

Voltage AC 100–240V (universal), 47–63Hz

Consumption 100W (typ)

CONTROLS

Basic Power, enter, channel +/-, volume +/-, menu

OnView® (PC Mode) Auto adjust, contrast, brightness, H. position, V. position, H.

size, fine tune, aspect ratio, information, text/graphic mode,

color temperature

(Video Mode) Picture (contrast, brightness, color, tint, sharpness, color

temperature), sound (volume, balance, bass, treble, equalizer,

SPDIF tuner, surround, reverb) input menu (TV, AV, S-video,

YCbCr, YPbPr, HDMI, VGA), parental control (caption, change

password, TV ratings, MPAA movie ratings, V-chip temporary

disable), setup menu (time out, language, memory recall)

(TV Mode) MTS, TV/CATV, auto scan, set channel, channel delete,

label, favorite, fine tune

OPERATING

Temperature 32–104°F (0–40°C)

CONDITIONS

Humidity 10–65% (non-condensing)

DIMENSIONS

Physical with stand 31.5"x 24.8"x 8.3" (800mm x 632mm x 210mm)

(W x H x D) Physical without stand 31.5"x 22.6"x 4.6" (800mm x 573mm x 117mm)

Packaging 35.7"x 30.1"x 11.0" (908mm x 765mm x 280mm)

WEIGHT

Net with stand 32.4 lb. (14.7 kg)

Net without stand 29.1 lb. (13.2 kg)

Gross 39.7 lb. (18.0 kg)

VESA® MOUNT

200mm x 400mm

REGULATIONS

cUL, FCC, NOM, EN 55013, CB, RoHS, BETS-7

RECYCLE/DISPOSAL

The lamp in this product contains mercury. Please dispose

of in accordance with local, state or federal law.

PACKAGE CONTENTS

LCD TV display, power cable(s), remote control with batteries,

Quick Start Guide, User Guide

MANUFACTURE STATED FEATURES

LCD Series N35W

720p native resolution.

Fast video response, high brightness and contrast ratio combine to deliver crystal clear, fast action movies, videos and games.

Advanced Clear Picture™ electronics enhance contrast, define details and boost color.

Dolby® Digital sound completes the experience with clear, digital audio for DVDs, movies, sports and games.

The glossy piano-black finish adds a splash of high-tech style to your home decor.

Picture quality: Average

Sound: GOOD

Connectivity: BELOW AVERAGE

REVIEW SUMMARY

If your looking for that bedroom TV and don’t want to spend a fortune then this ViewSonic might be for you! It offers entry level features and will perform well while viewing basic HD content and regular SD content. It uses advanced clear picture electronics to enhance contrast levels define details and boost color. The Dolby Digital sound completes the experience with life like sound.

Average Price

$463-$599

DISADVANTAGES

Other N35W Series

SIZE     MODEL     AVERAGE  PRICE

37”       N3735W    $829-$919

ADVANTAGES

MANUFACTURE:

ViewSonic

MODEL:

N3235W

32"

16:9

720p

1,200:1 (typ)

176º

8ms

Not Specified

1
